ASTM D1401 Semi Automatic Petroleum Demulsification Tester 0.1 Resolution Turbine Oil

SD7305 Petroleum Anti emulsification Tester

The SD7305 petroleum demulsifier is designed and manufactured in accordance with the requirements specified in the Chinese standards GB/T7305 "Determination of demulsification performance of petroleum and synthetic fluids" and GB/T7605-2008 "Determination of demulsification degree of turbine oil in operation". Applicable to the determination method proposed according to GB/T7305 standard, it can be widely used in fields such as petroleum, power, chemical engineering, as well as in colleges, research institutes and other units, equivalent to ASTMD1401 "Determination of Water Separability of Petroleum and Synthetic Liquids"

The demulsifier is used to determine the ability of petroleum and synthetic liquids to separate from water, and to measure the time of oil-water separation under specified conditions.

Main technical performance parameters

● Adopting a small cylinder desktop structure, it has the advantages of small volume, easy operation, and beautiful appearance.

● The bath is automatically stirred by a motor, ensuring uniform temperature. The bathtub cover has two sample holes, allowing for the simultaneous placement of two samples for testing.

● The sample stirring device is easy to lift and lower, and the stirring shaft has good concentricity inside the test tube without shaking or touching the test tube wall.

● Working power supply: AC 220V ± 10% 50Hz

● Temperature control range: Room temperature～100 ℃

● Temperature control accuracy: ± 1 ℃

● Temperature resolution: 0.1 ℃

● Temperature display format: digital display

● Time control range: 1s～ 99min59s

● Mixing speed: 1500 ± 15r/min

● Temperature controlled heating power: 1500W

● Environmental temperature: Room temperature ～35 ℃

● Relative humidity: ≤ 85%

● Power consumption of the whole machine: ＜ 1600W

● Instrument size: 320 * 380 * 680mm

● Weight: 15kg

Note: The appearance pictures, dimensions, volume, and weight of the instrument are for reference only. If there are any updates to the instrument, there may be slight changes without prior notice.

Shandong Shengtai Instrument Co., Ltd. provides the following quality assurance for the instruments sold to you:

----The provided instrument materials are brand new, meet national quality standards, and have a manufacturer's certificate of conformity;

----The materials and main components provided meet the technical requirements specified in the technical documentation;

----The overall quality assurance period of the equipment is one year (excluding normal wear and tear of vulnerable parts).

----We are responsible for free maintenance of any instrument quality issues that occur during the warranty period. Due to equipment malfunction caused by the user's responsibility, we are responsible for repairing and charging reasonable fees.

----Lifetime discounted supply of parts for equipment, and lifetime maintenance and repair of the entire machine.

----After the expiration of the warranty period, if the user needs maintenance and technical services, we will only charge a cost fee.

Packing list
