SD3536 Semiautomatic Open Flash Point Instrument For Petroleum Products

Place of Origin CHINA
Brand Name Shengtai Instrument
Certification ISO9001
Model Number SD3536
Minimum Order Quantity 1 Set
Packaging Details wooden case
Delivery Time 7-15work-days
Payment Terms T/T
Supply Ability 100000sets/year

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
MODEL SD3536 Power Supply AC(220±10%)V, 50Hz
Temperature Sensor RTD, PT100 Ambient Temperature (-10~50)ºC
Maximum Power Consumption 650W
High Light

Semiautomatic Open Flash Point Instrument

,

Petroleum Flash Point Instrument

Leave a Message
Product Description

SD3536 semi-automatic open flash point meter is designed and manufactured in accordance with the requirements specified in the People's Republic of China standard GB/T3536-2008 "Petroleum Products - Determination of Flash Point and Ignition Point - Cleveland Open Cup Method". It is suitable for measuring the flash point and ignition point of petroleum products except fuel oil and open flash point not less than 79 ℃, and also supports the determination of GB/T1671-2008 plasticizer flash point.



The open flash point is applicable to the determination of the flash point and ignition point of petroleum products except fuel oil and petroleum products with an open flash point not lower than 79 ℃

Semi-automatic Open Flash Point Tester

Semi-Automatic Cleveland Open Cup Flash Point Tester ASTMD92

SD3536Semi-automatic Cleveland Open-Cup Flash Point Tester

Semi-Automatic Tag Open Cup Flash Point Tester SD3536

SD3536Cleveland Open Cup Flash Point Tester for Oil testing



Main technical parameters and indexes

1. Power supply AC(220±10%)V, 50Hz.
2. Heating device electric furnace heating, no flame, explosion-proof, power 0-600W continuous adjustable.
3. Temperature control room temperature ~ 400℃, grading 2℃, technical conditions in line with the technical conditions of liquid thermometer used in petroleum products test GB/T514 provisions
4. Temperature display LCD screen shows temperature parameters. The range is 0ºC~400ºC, accuracy is 0.1ºC.
5. Ignition device

(1) Ignition source: gas (or other civil combustible gas, the same below);



(2) Nozzle aperture: 0.6 〜 0.8 mm.

6. Temperature sensor RTD, PT100
7. Ambient temperature (-10~50)ºC
8. Relative humidity ≤85%
9.Maximum power consumption 650W

10. Package size: 380mm * 290m * 260mm Weight: 10kg



SD3536 Semiautomatic Open Flash Point Instrument For Petroleum Products 0

Packing List

S/N NAME UNIT Quantity Remarks
1 Open flash point meter set 1
2 Special brass oil cup piece 1
3 Special thermometer piece 1
4 instructions copy 1
5 Certificate of conformity warranty card copy 1



Customers need to provide their own: air source and air source required pressure reducing valve

SD3536 Semiautomatic Open Flash Point Instrument For Petroleum Products 1

Company Introduction

Shandong Shengtai Instruments Co., Ltd. is specialized in the research and production of experimental testing instruments and industrial testing instruments. It is a professional instrument company integrating instrument research and development, manufacturing, sales and service. Its products are widely used in food, flour, grain and oil, Feed, electricity, petrochemical, industrial oil, aerospace, coal quality and other industries.

For more than 10 years, Shengtai has always been adhering to the "first-class service, customer first" as the purpose, "reasonable price, honesty and trustworthiness" as the business policy. Adhere to technical innovation, with rich knowledge of the technical team and experienced, thoughtful after-sales service team.

Shengtai instrument as one of the most large-scale and competitive enterprises in the industry, with the strength of technology research and development, professional technical knowledge and innovative design concept, in the model improvement, Significant technical breakthrough has been achieved in the development of function expansion and intelligent control system.

OUR service

After-sales service commitment, our company to sell the product after-sales service commitment: warranty period of one year, long-term technical support outside the warranty period. During the warranty period, the seller shall bear the cost of the replacement of the equipment, the freight and maintenance of the instrument; outside the warranty period, the seller shall waive the maintenance fee and charge only the cost of the basic materials and freight charges when the instrument is malfunctioning and the seller shall not charge the maintenance fee during the warranty period.

Packaging & Delivery

1. Out packing: Standard export wooden case.
2. Inner packing: With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.

4.Port Any port of China

Lead Time :

Quantity(Sets) 1 - 1 2 - 5 6 - 10 >10
Est. Time(days) 6 20 30 To be negotiated
