Automatic Pharmaceutical Testing Instruments Vaseline Ointment Dropping Point Apparatus

automatic Vaseline drop point meter ointment drop point tester Chinese pharmacopoeia England pharmacopoeia

    ST212B fully automatic Vaseline ointment drop point meter meets the 2020 Chinese pharmacopoeia standard and England pharmacopoeia , with microprocessor as the core, it integrates mechanical, photo electronic and micro detection technology, and has the functions of automatic temperature rise control, automatic adjustment of temperature rise rate, automatic detection and recording of drop point data, automatic printing and output, etc., to complete the measurement of drop point.

   Main Features and parameter

1.7 "touch screen display;

2.Imported temperature sensor to ensure accurate and stable temperature measurement and control;

3.Metal bath heating, no noise, no pollution, fast heating rate;

4.High temperature resistant special optical fiber is used for droplet detection.

5.Equipped with internal clock, no need to enter experimental date.

6.Applicable standards:Chinese Vaseline ointment 2020

7.Temperature measurement range: room temperature ~ 400 ℃ Resolution: 0.1℃

8.Number of test holes: 2

9.Ambient temperature: 10℃ ~ 35℃

10.Temperature control precision of metal bath: ±1℃

11.Environmental relative humidity: 30 ~ 80%RH

12.Power supply: AC220± 10% V 50HZ±1HZ

13.Power supply: less than 2KW

14.Typing: Chinese or English character printing

15.Printer: Small thermal printer

16.Detection mode: imported high-precision optical fiber detection

17.Curve display: Display the trend chart of temperature time curve

18.Storage: Experimental results can be stored in 199 groups of historical data for easy query;

19.Result output: At the same time can be equipped with U disk output function, output to the computer end for long-term storage

20.Output format: The output format of the usb flash disk is CSV or Excel.

21.Standard printing: standard printing with micro printer automatic measurement automatic thermal sensitive printing

22.Remote upgrade: With TCP network transmission function, software remote upgrade can be carried out later

23.Data management: Can connect to limIS system

24.Data memory: Microcomputer instrument memory can be expanded to 16 gigabytes.

25.Account management: According to the password to set up the account management layer, can set up the total account and sub-account.

OUR service

After-sales service commitment, our company to sell the product after-sales service commitment: warranty period of one year, long-term technical support outside the warranty period. During the warranty period, the seller shall bear the cost of the replacement of the equipment, the freight and maintenance of the instrument; outside the warranty period, the seller shall waive the maintenance fee and charge only the cost of the basic materials and freight charges when the instrument is malfunctioning and the seller shall not charge the maintenance fee during the warranty period.

Packaging & Delivery

1. Out packing:Standard export wooden case.
2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.

4.Port Any port of China

Lead Time :
