0.1cm Grease Viscosity Testing Equipment Using PID Automatic Control System

0.1cm Grease Viscosity Testing Equipment Using PID Automatic Control System
0.1cm Grease Viscosity Testing Equipment Using PID Automatic Control System

Large Image :  0.1cm Grease Viscosity Testing Equipment Using PID Automatic Control System

Product Details:
Place of Origin: china
Brand Name: Shengtai Instrument
Model Number: SH0048
Payment & Shipping Terms:
Minimum Order Quantity: 10-99 Sets
Price: $5,000.00
Packaging Details: Wooden box
Delivery Time: About 5 working days
Payment Terms: T/T
Supply Ability: 1000 set per mouth

0.1cm Grease Viscosity Testing Equipment Using PID Automatic Control System

Description
Product Name: Similar Viscometer Weight: 70kg
Power Supply: AC 220V 50HZ Warranty: 1 Year
Keyword: Grease Similar Viscometer Selling Units: Single Item
Single Package Size : 35X38X95 Cm Single Gross Weight: 65.000 Kg
High Light:

grease similar viscometer Equipment

,

0.1cm Viscosity Testing Equipment



Product Description



 SH0048 grease similar viscometer is used to determine the similar viscosity of grease specified by SH/T0048-91. Instrument equivalent 7163 Standard for determination of similar viscosity of Grease.

Similar viscometer Characteristic:

1.spring-pressure type capillary viscometer

2.The height and direction can be adjusted arbitrarily on the column.

3.The recorder can have three revolutions to choose from

low temperature cycle device Characteristic:

1.Refrigeration of fully enclosed compressor unit, refrigeration system has multiple protection devices for overheating and overcurrent.

2.Using PID automatic control system, LCD liquid crystal temperature digital display

Technical parameters

1. Standard capillary size:0.025, 0.05, 0.1cm

2.Comparison of rotational Speed and Linear Speed of recording Paper

Number of files

Speed (r/ min)

Linear velocity (cm / s)

1

0.1111

0.0054

2

0.195

0.094

3

3.42

1.65

 0.1cm Grease Viscosity Testing Equipment Using PID Automatic Control System 0

3.Input power supply: 220V ± 10% 50HZ

4. Machine power: 1.5KW

5. Stirring motor: 4W 1250r / min

6. Temperature range: room temperature ~ -40 ℃(single compressor refrigeration) or -70 ℃(dual compressor cascade refrigeration)

7. Temperature control accuracy: ± 0.5 ℃

8. Test hole: single hole

9. Ambient temperature: room temperature about 25 ℃

10. Relative humidity: <85% RH



Our Services



 We advocate a technical marketing model, is a professional service, a pre-sale service, in-sales service and after-sales service throughout the body of trusted professional services.

Pre-sales service to provide customers with pre-sales technical advice, design of the test plan, assist users to complete the test, assist users in making inquiries for special auxiliary equipment for components.

After the contract is signed, we still negotiate and communicate with the user, confirm the specific test items and specific test requirements of the user, and communicate with the user's user department or user further. To ensure that the equipment provided to the user can fully meet the overall requirements of the user.

After-sales service commitment, our company to sell the product after-sales service commitment: warranty period of one year, long-term technical support outside the warranty period. During the warranty period, the seller shall bear the cost of the replacement of the equipment, the freight and maintenance of the instrument; outside the warranty period, the seller shall waive the maintenance fee and charge only the cost of the basic materials and freight charges when the instrument is malfunctioning and the seller shall not charge the maintenance fee during the warranty period.



Company Information



Shandong Shengtai Instruments Co., Ltd. is specialized in the research and production of experimental testing instruments and industrial testing instruments. It is a professional instrument company integrating instrument research and development, manufacturing, sales and service. Its products are widely used in food, flour, grain and oil, Feed, electricity, petrochemical, industrial oil, aerospace, coal quality and other industries.



For more than 10 years, Shengtai has always been adhering to the "first-class service, customer first" as the purpose, "reasonable price, honesty and trustworthiness" as the business policy. Adhere to technical innovation, with rich knowledge of the technical team and experienced, thoughtful after-sales service team.



Shengtai instrument as one of the most large-scale and competitive enterprises in the industry, with the strength of technology research and development, professional technical knowledge and innovative design concept, in the model improvement, Significant technical breakthrough has been achieved in the development of function expansion and intelligent control system.
