ASTM D892 LCD foam tester is displayed on the LCD color screen

Place of Origin CHINA
Brand Name Shengtai instrument
Certification ISO9001
Model Number SH126B
Minimum Order Quantity 1
Packaging Details wooden case
Delivery Time 7-15work-days
Payment Terms T/T
Supply Ability 100000sets/year

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
MODEL SH126B Working Power Supply AC220V±10%, 50Hz
Temperature Control Mode LCD Display Temperature Control Accuracy ±0.1℃
Temperature Control Range 5~99.9℃ With Refrigerators Timing Accuracy ±0.05 Seconds
Ambient Temperature -10~+40℃ Relative Humidity ≤85%
High Light

agriculture lab equipment


leaf area measuring instrument

Leave a Message
Product Description

  SH126B liquid crystal foam tester is designed according to GB/T12579-90 "Lubricating Foam Performance Determination Method" and ASTMD892. It is used to determine the foam characteristics of engine lubricating oil, gear oil, hydraulic oil and other oil products to evaluate the foam tendency of lubricating oil and the degree of foam stability.

Lubricants Testing Equipment Double Baths ASTM D892 Foam Characteristics Tester

ASTM D892 Lubricants Foaming Tendencies Analyzer Lubricating Oil Foam Characteristic Tester

Lubricating Oils Testing Laboratory ASTM D892 Foam Test Equipment

ASTM D892 Foaming Characteristics of Lubricating Oils Analyzer

The instrument is controlled by dynamic temperature control, automatic timing, air source and gas flow centralized control, 32-bit ARM processor control, high-definition color touch screen display, PID temperature control and setting technology has the advantages of accurate test temperature and high constant temperature accuracy.

The instrument can be operated according to the test method of GB/T12579-90 "Determination of Lubricating Oil Foam Performance".Foam Testing Equipment Electronic for Lubricating Oils ASTM D892 & GB/T12579 Bubble Tester

Used for testing fuel oil, lubricating oil, gear oil, hydraulic oil and other oil products.

II. Technical parameters

working power supply AC220V±10%, 50Hz
temperature control mode LCD display
Temperature control range 5~99.9℃ with refrigerators

Temperature control accuracy:




temperature measuring element platinum resistance (PT100)
the number of tests double bathtub, can do 2 samples at the same time
the test cylinder specification 1000mL (special cylinder)
diffuser air permeability at 2.4kPa (250mmH2O) pressure of 3000 ~ 6000mL/min;
timing accuracy ±0.05 seconds
heating power heater power: 2500W (93.5℃ bathtub) 800W (24℃ bathtub)
timing accuracy 0.01%+0.05 seconds (at 20℃)
ambient temperature -10~+40℃
relative humidity ≤85%
Power consumption of the whole machine no more than 3000W.
Gas diffuser diameter: 25.4mm.
Instrument size: 680 * 380 * 550mm Weight: 35kg



Packing list

S/N Name Quantity unit Remarks
1 Host 1 set
2 Portable refrigerating plant 1 set
3 Measuring cylinder 4 piece
4 Foam head 4 piece
5 Gauge plug 4 piece
6 Rubber hose 2 meter
7 Thermometer 1 piece
8 Power cord 1 piece
9 Fuse tube 1 piece 10A
10 Instruction manual 1 copy
11 Packing list 1 copy
12 Certificate 1 copy

Company Introduction

Shandong Shengtai Instruments Co., Ltd. is specialized in the research and production of experimental testing instruments and industrial testing instruments. It is a professional instrument company integrating instrument research and development, manufacturing, sales and service. Its products are widely used in food, flour, grain and oil, Feed, electricity, petrochemical, industrial oil, aerospace, coal quality and other industries.

For more than 10 years, Shengtai has always been adhering to the "first-class service, customer first" as the purpose, "reasonable price, honesty and trustworthiness" as the business policy. Adhere to technical innovation, with rich knowledge of the technical team and experienced, thoughtful after-sales service team.

Shengtai instrument as one of the most large-scale and competitive enterprises in the industry, with the strength of technology research and development, professional technical knowledge and innovative design concept, in the model improvement, Significant technical breakthrough has been achieved in the development of function expansion and intelligent control system.

OUR service

After-sales service commitment, our company to sell the product after-sales service commitment: warranty period of one year, long-term technical support outside the warranty period. During the warranty period, the seller shall bear the cost of the replacement of the equipment, the freight and maintenance of the instrument; outside the warranty period, the seller shall waive the maintenance fee and charge only the cost of the basic materials and freight charges when the instrument is malfunctioning and the seller shall not charge the maintenance fee during the warranty period.

Packaging & Delivery

1. Out packing: Standard export wooden case.
2. Inner packing: With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.

4.Port Any port of China

Lead Time :

Quantity(Sets) 1 - 1 2 - 5 6 - 10 >10
Est. Time(days) 6 20 30 To be negotiated
